Globe Valves

Globe Valves

Globe valves throttle or shut off flow through a movable disc that seats against a fixed ring inside an S-shaped body, giving finer control than a gate valve. NLS sources forged and cast steel globe valves built to API 602 and API 600, dimensioned to ASME B16.34, for steam, condensate, and process throttling duty on Saudi industrial projects.

A globe valve closes by lowering a disc straight down onto a seat ring, with flow forced to change direction as it passes through the body. That change in flow path is what gives the valve its throttling ability: unlike a gate valve, which is built for full-open or full-closed duty, a globe valve holds a stable position anywhere in between without the disc wearing unevenly. The tradeoff is a higher pressure drop across the valve even when fully open, since the flow never travels in a straight line.

NLS sources globe valves in two size ranges that follow two different standards. Small forged steel valves, typically 2 inches and under, are built to API 602, the standard covering compact bolted-bonnet valves for high-pressure, small-bore piping common on instrument and utility lines. Larger cast steel globe valves reference API 600 body and pressure-temperature practice, the same family gate valves are built to, since both share bolted-bonnet and flanged-end construction principles. Face-to-face and pressure-temperature ratings across both ranges follow ASME B16.34, so a globe valve dropped into a piping isometric matches its neighboring gate or check valve on centerline and rating without a special spool piece.

On Saudi projects, globe valves show up most on steam and condensate lines, boiler feedwater systems, and process lines where an operator needs to trim flow rather than just start or stop it, common in utility plant rooms and process skids on industrial and hospital infrastructure builds. Bonnet type (bolted, pressure-seal, or welded) and trim material (usually 13% chrome or stellite-faced for steam service) both depend on line temperature and the erosive or corrosive nature of the fluid, so NLS confirms trim spec against the line's service conditions before quoting rather than defaulting to a standard trim.

NLS quotes globe valves against a valve schedule, P&ID, or line list and returns pricing in USD. Small forged API 602 valves in standard trim generally source faster than larger API 600 cast valves, which are more often built to order once size, rating, and trim are confirmed, and carry a manufacturer-stated lead time on the quote.

Specifications

  • ✓Small forged steel bodies built to API 602 for high-pressure, small-bore piping 2 inches and under
  • ✓Larger cast steel bodies follow API 600 body and pressure-temperature practice
  • ✓Face-to-face dimensions and pressure-temperature ratings per ASME B16.34
  • ✓Bolted bonnet, pressure-seal, or welded bonnet construction depending on line rating
  • ✓Trim options including 13% chrome and stellite-faced discs for steam and erosive service
  • ✓Flanged, socket-weld, or threaded end connections to match the piping spec
  • ✓Pressure classes typically ANSI 150 through 1500

Frequently Asked Questions

Who supplies globe valves for steam service in Saudi Arabia?+

NLS sources forged and cast steel globe valves built to API 602 and API 600, with steam-rated trim in chrome or stellite-faced discs, quoted against the project's line list or P&ID.

What's the difference between a globe valve and a gate valve?+

A gate valve is built for full-open or full-closed isolation with minimal pressure drop. A globe valve trades some pressure drop for the ability to hold a stable throttled position anywhere in between, which is why it's the default choice for flow control rather than simple isolation.

Can NLS quote globe valves matched to an existing piping isometric?+

Yes. Send the valve schedule or isometric with size, rating, and service, and NLS returns a USD quote with body material and trim matched to the line's pressure, temperature, and fluid conditions.

Who supplies Globe Valves in Saudi Arabia?+

NLS Industries (Northlane Solutions Company) supplies Globe Valves across Saudi Arabia, including Riyadh, Jeddah, Dammam and Jubail. Send your specification and quantities to info@nlsindustries.com or info@northlanesolution.com for a quotation.
